Inverted “T” & Trapeze Hanger (Crossbars)

Inverted T Trapeze Hanger Crossbars



For applications where cable must be run through areas with limited overhead space, the over and under style system with over and under cross
bars #19000-OU is available. It is identical to the #19000- cross bar except that it is has an extra tier to facilitate another layer of cable.

The Inverted “T” & Trapeze Over And Under System is available in high weldable grade steel and type 304 or 316 stainless steel.

The Inverted “T” & Trapeze Over and Under System conforms to the test arrangement criteria of Navships DWG.9000-S6202-73980, section 1 sheet G
and has been successfully tested to MIL-S-901C, Grade A, Class 1 shock, and MIL-STD-167-1, Type 1 (5-15 Hz) vibration.

The Inverted “T” & Trapeze Over and Under System is manufactured in complete accordance with the detail specifications outlined in Navships
DWG.9000-S6202-73980, with all banding slots in the cross bar having complete capability for use with standard banding methods or “Snaplock”
cable clamps.
