Tubular Rectangular

Prod Id Length A Weight per 100 pcs
0150 1.50 9 lbs
0250 2.50 13 lbs
0350 3.50 17 lbs
0450 4.50 22 lbs
0550 5.50 26 lbs
0650 6.50 31 lbs
0750 7.50 36 lbs

How To Install PFS Tubular Type Cable Hangers:

Easy and quick to install, PFS crimp type cable hangers support single up to four cable installations. Crimp type cable hangers fasten to 3/8 – 16 weld studs or metric M-10 diameter studs which are available upon request.

After weld is installed:

  1. Determine number of cables to be supported.
  2. Determine diameter of cables.
  3. Select from PFS chart the correct diameter range to accept desired cable.
  4. Install cable into hanger.

See how Tapped Cable Hangers Work
