How To Install PFS Tapped Crimp Type Cable Hangers:
Easy and quick to install, PFS crimp type cable hangers support single up to four cable installations. Crimp type cable hangers fasten to 3/8 – 16 weld studs or metric M-10 diameter studs which are available upon request.
After weld is installed:
- Determine number of cables to be supported.
- Determine diameter of cables.
- Select from PFS chart the correct diameter range to accept desired cable.
- Install cable into hanger.
- Using channel lock pliers, locate two tines at the edge of the crimp type hanger and squeeze down to form tine over cable and lock.
. . . . . . . . . . . . .
