Eagle Capacitor Discharge Stud Welder

Midwest Fasteners Eagle Welder



Midwest Fasteners Eagle Welder

  • Quick-charge Transformer
  • Stepless voltage Control
  • Digital LED Voltage Meter
  • On-Board LED Diagnostics
  • Visible On/Off Switch
  • Diagnostic L.E.D.’s
  • Lightweight Easy-Grip Gun



Learn about our Rental FleetIf you weld pins, nails, or even studs up to 1/4″, Eagle delivers the performance you should expect from a portable pin welding system! Eagle’s superior welding performance results from the proven technology we introduced two years ago with TALON, the lightweight system that revolutionized the industry for Cuphead pin welding.Eagle is perfect when Cuphead pins aren’t needed and comes in a lighter, more portable package than TALON. It’s priced less too. And Eagle continues our built-in innovations to make it the most user-friendly system available.Best of all, Eagle can be counted on day-in and day-out, even in extreme environments. And it comes with a Full Three Year Manufacturer’s Warranty to back it up!

Land an Eagle and watch production suddenly take off on your next pin welding job!

Printable Specsheet



Specifications



Height 8-1/2″
Width 10″
Depth 13″
Weight 26 lbs.
Weld Rate Up to 20/Min.
Weldable Materials Mild Steel, Stainless Steel, Aluminum
Pin/Stud Range 14 GA, thru 1/4″ Dia. Weld Base
Weld Voltage 35-175 VDC
Capacitance 70,000 Mfd
Weld Mode Contact
Power Requirement 115 VAC, 60 Hz, 20 Amp



Weld Gun



Weight 1.6 lbs. (not including cable)
Size 4-7/8″ x 2″ x 5-3/4″
Weldable Dia. 14 Ga. thru 1/4″ Dia. Weld Base
Material High strength, impact resistant polycarbonate



Cables



Ground Cable #4 x 15 ft. (One Each)
Gun Extension Set #4 x 18/2 x 35 ft. (Direct to Gun)



Features



  • Quick-charge Transformer – Enjoy lighting fast duty cycles and excellent load-to-duty cycle characteristics. Eagle’s newer, compact-design transformer offers outstanding balance between low weight and high performance.
  • Stepless voltage Control – Infinite weld-heat settings are now attainable with EAGLE’s “true” variable voltage control. At your fingertips is the full range of capacitance for all applications and the industry’s first “turn-down” feature.
  • Digital LED Voltage Meter – What you set is what you get! Operator’s love EAGLE’S large, color display of voltage settings. The high-definition LED read-out is easy to see on all types of jobs.
  • On-Board LED Diagnostics – Now you can troubleshoot welder problems anywhere they occur. Immediately! Front panel, color-coded LEDs help you to evaluate system status in an instant or pre-test your system before use in the field.
  • Visible On/Off Switch – Eagle’s large, lighted On/Off toggle switch is easy to see. A separate, built-in circuit breaker eliminates fuses, protects your EAGLE and is easy to access.
  • Lightweight Easy-Grip Gun – Crafted from high impact, nonconductive polycarbonate, its hand-friendly design continues our standard to easily adapt to all applications. parts and accessories are interchangeable and accessible for quick changeover.
