HBS-CDM-2401  Stud Welding Unit (with wide range power supply)

CD stud welding (capacitor discharge welding) according to current standards.
Learn about our Rental Fleet

Application

  • Especially suitable for thin sheets (at least 0.5 mm)

Process variants

  • Contact welding
  • Gap welding



Equipment

  • Automation (series)



Technical Data



Automation Series
Welding range #4 to 5/16″ (7/16″ limited), dia. 14 ga to 5/16” (dia. 3/8″ limited) (M3 to M8 (M10 limited), dia. 2 to 8 mm (dia. 10 mm limited))
Welding material Mild steel, stainless steel, aluminum and brass
Welding rate 20 to 40 studs/min (depending on application and stud dia.)
Capacitance 99,000 F/33,000 F (with change over of capacitors)
Welding time 1 to 3 msec
Energy 2,400 Ws/800 Ws (with change over of capacitors)
Charging voltage 50 to 220 V (stepless voltage regulation)
Primary power 85 to 265 V ~ wide range selection, 50/60 Hz, 10 AT
Power source Capacitor
Cooling type F (temperature controlled cooling fan)
Protection class IP 21
Operational and storage conditions According to current standards
Dimension L x W x H 23.62″ x 9.45″ x 11.02″ (600 x 240 x 280 mm) without handle
Weight 57.32 lbs (26 kg)
Order No. 92-12-2241 (Automation)



Advantages



Features

  • Microcontroller – for precise process times, optimal functional reliability and maximum operating convenience
  • Function monitoring – automatic function test following power-up; monitoring of all internal system functions
  • Display of error codes – on LCD display
  • Lift test – for gap welding guns and stud welding heads
  • Library function – 8 programs (charging voltages) can be stored; library with stored welding parameters; additional
    customer-specific entries possible; user interface available in various languages; display of charging voltage in volts
  • Process monitoring – recording and analysis of factors affecting the welding process by means of the process-analysis
    factor (PAF); after each weld, the reference PAF value is compared with the actual value; display of the actual and
    reference values; switchable automatic welding stop, if limits are exceeded; limits selectable in increments; manual entry
    of PAF value possible
  • RS232 interface – for data output; data and time of day are stored; welding parameters of each weld are logged



Structure

  • Extremely easy to operate
  • Compact
  • Robust – metal housing withstands rough treatment in shop and on site



Safety

  • With integrated mains filter (protection against voltage peaks)
  • Optimal for construction sites with large mains voltage fluctuations – safe to operate with mains voltages ranging between 85 to 265 V (wide range power supply); use even with critical voltage supply
  • EMC test
  • High-voltage test with log
  • Retriggering lock-out – prevents welding on a welding element that has already been set
  • Thermal monitoring of transformer and internal temperature of stud welding unit- automatic shutdown in case of overheating
  • Temperature-regulated ventilator – reduces noise and dust in the stud welding unit (greater system reliability)
  • Control unit galvanically separated from welding lines – high degree of functional safety
  • Optimal protection against external interferences



Welding

  • Display – infinitely adjustable power setting (charge reversal via set-point switch); easy monitoring of all functions via LCD display; user-friendly operation via large LCD display
  • Powerful – built-in power reserves
  • Electronic regulation of charging – allows high clock rates
  • Trouble-free changing of welding voltage polarity possible by reconnecting welding current and ground cables
  • Use of special capacitors (developed for stud welding)
  • Capacitance switching – 33,000 F or 99,000 F



Suitable Welding Guns

  • C 08
  • CA 08
  • PAH-1
  • KAH 412
  • KAH 412 LA
