HBS-AI-06 Stud Welding Gun (for insulation)

ARC stud welding according to current standards.


Application



  • Especially suitable for thicker metal sheets from approx. 2 mm
  • ISO – especially suitable for welding on ARC-ISO and Fiberfix pins
  • Automatic compensation of length tolerance of welding elements through integrated length adjustment



Process variants



  • Short cycle drawn arc welding
  • Drawn arc welding with ceramic ring or shielded gas



Technical Data



Welding range ARC-ISO pins dia. #4 to 1/4″ (dia. 3 to 6 mm)
Pin length 0.39″ to 15.74″ (10 to 400 mm) depending on tripod
Pin material Mild steel, stainless steel
Pin type ARC insulation pin, ARC fiberfix pin, ARC threaded stud, ARC pin
Length compensation 0.12″ (3 mm) automatic
Stroke Adjustment range 0.12″ (3 mm), lockable
Spring pressure Adjustable, arresting
Welding cable 32.81′ (10 m)
Insulation class IP 20
Workplace noise level Up to 90 dB (A) may occur during welding
Operational and storage conditions According to current standards
Dimension L x W x H 7.09″ x 2.56″ x 5.51″ (180 x 65 x 140 mm) without cable, with foot piece
Weight 1.76 lbs (0.8 kg) without cable and tripod
Order No. 93-20-250 (gun including foot piece)93-40-026 (tripod ISO with support tube)

93-40-066 (tripod ISO with support tube aluminum-teflon)



Advantages



Structure



  • Rigid casing made of impact-resistant plastic
  • Torsion-resistant basic shell (casing) to accommodate all function elements and accessories (e.g. foot ring)
  • Zero-play ball linear bearing for guiding the welding piston
  • Sealed welding piston guidance
  • Ergonomic design
  • Compact dimensions
  • Integrated lift and spring-loaded adjustment
  • Stud length freely adjustable
  • Mechanical structure tested in production



Safety



  • Lock-in spring adjustment
  • Lift lockable
  • High level of security to prevent the selected settings being changed inadvertently
  • Guidance system protected against spatters



Welding



  • Individual adjustment options for optimum welding results
  • Reproducible piston movement with minimized rebound effect for optimum welding quality via lift damper
  • Optimum handling and fatigue-free operation
  • Optimum operation also at places that are difficult to access
  • Welding on painted sheets possible (clean, smooth and flat surfaces and grounding required)
  • Automatic length compensation
