HBS-C-06 Stud Welding Gun



CD stud welding according to current standards.



Application



  • Especially suitable for thin sheets (at least 0.5 mm)
  • ISO – especially suitable for welding on insulation pins with flange and ignition tip



Process variants



  • Contact welding – capacitor discharge welding elements and cupped head pins (one stud welding gun for two applications)



Equipment



  • Welding with ceramic ferrule (series)
  • Welding with shielding gas (series)
  • Automation (optional)



Technical Data



Welding range #4 to 1/4″, dia. 14 ga to 1/4″ (M3 to M6, dia. 2 to 6 mm); cupped head pins dia. 14 ga to 10 ga (dia 2 to 3.1 mm)
Stud length 0.24″ to 1.57″ (6 to 40 mm); longer studs can be welded with optional accessories
Stud material Mild steel, stainless steel, brass
Stud type Any type or shape (special chucks if required)
Welding rate 32.81′ (10 m)
Insulation class IP 20
Workplace noise level > 90 dB (A) may occur during welding
Operational and storage conditions According to current standards
Dimension L x W x H 6.70″ x 1.57″ x 5.51″ (170 x 40 x 140 mm) without cable
Weight 1.10 lbs (0.5 kg) without cable
Order No. 92-20-270



Advantages



Structure



  • Rigid casing made of impact-resistant plastic
  • Torsion-resistant basic shell (casing) to accommodate all function elements (e.g. ball bearing guide) and accessories (e.g. foot ring)
  • Slide bearing for guiding the welding piston
  • Sealed welding piston guidance
  • Ergonomic design
  • Compact dimensions
  • Stud length freely adjustable (up to 40 mm; from 40 mm with tripod)
  • Mechanical structure tested in production



Safety



  • High level of security to prevent the selected settings being changed inadvertently
  • Guidance system protected against spatters



Welding



  • Optimum handling and fatigue-free operation
  • Optimum operation also at places that are difficult to access
  • Welding on painted sheets possible (clean, smooth and flat surfaces and grounding required)
