HBS-C-08 Stud Welding Gun

CD stud welding according to current standards.

Application

  • Especially suitable for thin sheets (at least 0.5 mm)
  • ISO – especially suitable for welding on insulation pins with flange and ignition tip

Process variants

  • Contact welding

Equipment

  • Welding with ceramic ferrule (series)
  • Welding with shielding gas (series)
  • Automation (optional)

Technical Data

Welding range #4 to 5/16”, dia. 14 ga to 5/16″ (M3 to M8, dia. 2 to 8 mm) other dimensions on request
Stud length 0.24″ to 1.57″ (6 to 40 mm); longer studs can be welded with optional accessories
Stud material Mild steel, stainless steel, brass
Stud type Any type or shape (special chucks if required)
Spring pressure Adjustable, arresting
Welding cable 21.33′ (6.5 m)
Insulation class IP 20
Workplace noise level > 90 dB (A) may occur during welding
Operational and storage conditions According to current standards
Dimension L x W x H 6.70″ x 1.57″ x 5.51″ (170 x 40 x 140 mm) without cable
Weight 1.10 lbs (0.5 kg) without cable
Order No. 92-20-256

Advantages

Structure

  • Rigid casing made of impact-resistant plastic
  • Torsion-resistant basic shell (casing) to accommodate all function elements (e.g. ball bearing guide) and accessories (e.g. foot ring)
  • Zero-play ball linear bearing for guiding the welding piston
  • Sealed welding piston guidance
  • Ergonomic design
  • Compact dimensions
  • Stud length freely adjustable (up to 40 mm; from 40 mm with tripod)
  • Mechanical structure tested in production

Safety

  • Lock-in spring adjustment
  • A high level of security to prevent the selected settings from being changed inadvertently
  • Guidance system protected against spatters

Welding

  • Individual adjustment options for optimum welding results
  • Optimum handling and fatigue-free operation
  • Optimum operation also at places that are difficult to access
  • Welding on painted sheets is possible (clean, smooth, and flat surfaces and grounding required)

.
