HBS-CA-08 Stud Welding Gun

CD stud welding according to current standards.



Application



  • Especially suitable for thin sheets (at least 0.5 mm)



Process variants



  • Gap welding
  • Short cycle drawn arc welding



Equipment



  • Welding with ceramic ferrule (series)
  • Welding with shielding gas (series)
  • Automation (optional)



Technical Data



Welding range #4 to 5/16”, dia. 14 ga to 5/16″ (M3 to M8, dia. 2 to 8 mm) other dimensions on request
Stud length 0.24″ to 1.57″ (6 to 40 mm); longer studs can be welded with optional accessories
Stud material Mild steel, stainless steel, aluminum, brass
Stud type Any type or shape (special chucks if required)
Stroke Adjustment range 0.18″ (4.5 mm), lockable
Spring pressure Adjustable, arresting
Welding cable 9.84′ (3 m)
Insulation class IP 20
Workplace noise level > 90 dB (A) may occur during welding
Operational and storage conditions According to current standards
Dimension L x W x H 7.48″ x 1.57″ x 5.51″ (190 x 40 x 140 mm) without cable
Weight 1.54 lbs (0.7 kg) without cable
Order No. 92-20-255



Advantages



Structure



  • Rigid casing made of impact-resistant plastic
  • Torsion-resistant basic shell (casing) to accommodate all function elements (e.g. ball bearing guide) and accessories (e.g. foot ring)
  • Zero-play ball linear bearing for guiding the welding piston
  • Sealed welding piston guidance
  • Ergonomic design
  • Compact dimensions
  • Integrated lift and spring-loaded adjustment
  • Stud length freely adjustable (up to 40 mm; from 40 mm with tripod)
  • Mechanical structure tested in production



Safety



  • Lock-in spring adjustment
  • Lift lockable
  • High level of security to prevent the selected settings being changed inadvertently
  • Guidance system protected against spatters



Welding



  • Individual adjustment options for optimum welding results
  • Optimum handling and fatigue-free operation
  • Optimum operation also at places that are difficult to access
  • Welding on painted sheets possible (clean, smooth and flat surfaces and grounding required)
