Pad Welding Machine PC-M3 for pad welding with rotating arc.


Application



  • The most innovative process for welding pad type elements
  • To be used for nearly any application in metal working industry: The very low heat input avoids any distortion of the work piece and you get a perfect gas-tight weld with high and dynamic loading capacity
  • The most effective as well as most economical welding procedure for the welding hollow cylindrical parts
  • Closed and pressure sealed weld all-over
  • The welding requirements are manifold, reaching from the simplest static firmness to dynamic demanded gas tight connections at high temperature and pressure
  • Austenitic stainless steel (1.4301 and similar), low alloys (RSt 37-2 / S 235J2G3)
  • High productivity together with low manufacturing costs
  • No need for additional welding cons
  • Free programmable welding head



Process variants



  • Pad welding with magnetic rotating arc



Technical Data



Welding range Min. dia. 1/4″ (dia. 6 mm), max. dia. 1.18″ (dia. 30 mm) or internal thread #8 to 0.71″ (M4 to M18)
Height of pad Min. 0.16″ (4 mm), max. 1.18″ (30 mm)
Welding material Weldable, high and low alloys, mild steel
Welding rate Depending on dia. 12 pieces/min (dia. 1.10″ (dia. 28 mm) approx. 2 to 4 pieces/min)
Welding current 300 to 1,000 A stepless remote controllable
Welding time 5 to 3,000 msec stepless remote controllable
Primary power 480 V, 32 A (IT 1001); 115/230 V (PC-M3)
Gas connection Series
Air pressure connection 6 bar/inner hose dia. 1/4″ (dia. 6 mm)
Power source Inverter
Controller IPC Pentium P III, 500 MHz
Programming modes Welding current, welding time, any motion profile, welding piston, shielding gas
Welding head Linearmotor driven
Field former unit Tempered
Pneumatic work stroke 4.72″ (120 mm)
Height adjustment 9.84″ (250 mm)
Order No. According to project



Advantages



Features



  • Welding head with linear motor
  • Integrated process control for quality assurance
  • PC-controlled
  • Welding time approx. 800 msec with dia. 30 mm



Structure



  • High performance, extremely easy to operate, robust, reliably



Welding



  • CNC controlled
  • Minimum plate thickness ≈ 1 mm, maximum plate thickness ≈ 4 mm
  • Minimum wall thickness of pad in the welding section ≈ 1 mm
  • Welding in vertical and overhead positions is possible (up to M8/M10)
  • Welding of end caps on pipes
  • Gas tight to over 250 bar (M10)



Description



  • Low energy consumption
  • Even and minimal heat input (low distortion)
  • Very short welding time (≤ 1 second) and consequently short cycle time in production
  • No welding additives required
  • Minimum upsetting force
  • Small and even welding seam
  • Only one-sided accessibility to the work piece required
  • Low investment costs for machine technique
  • Extremely clean process (minimum development of airborne particles)
  • No reworking of work piece or welding element (thread)
