HBS-PAH-1Â Stud Welding Gun (damped)
ARC stud welding according to current standards.
Applications
- Especially suitable for thin sheets (at least 0.5 mm)
Process variants
- Contact welding (optional)
- Gap welding
- Short cycle drawn arc welding
Technical Data
| Welding range | #4 to 5/16″, dia. #4 to 5/16″ (M3 to M8, dia. 3 to 8 mm) |
|---|---|
| Stud length | 0.31″ to 1.18″ (8 to 30 mm) |
| Stud material | Mild steel, stainless steel, aluminum, brass |
| Stroke | Adjustment range 0.20″ (5 mm) |
| Welding cable | 9.84′ (3 m) |
| Insulation class | IP 20 |
| Workplace noise level | > 90 dB (A) may occur during welding |
| Operational and storage conditions | According to current standards |
| Dimension L x W x H | 11.61″ x 2.36″ x 6.70″ (295 x 60 x 170 mm) without cable |
| Weight | 3.09 lbs (1.4 kg) without cable |
| Order No. | 94-20-015 |
Advantages
Structure
- Rigid casing made of impact-resistant plastic
- Slide bearing for guiding the welding piston
- Sealed welding piston guidance
- Ergonomic design
- Adjustable lift
- Stud length convertible (up to 30 mm)
- Mechanical structure tested in production
- Electronically controlled
Safety
- Secure lift adjustment (with lock nut)
- High level of security to prevent the selected settings being changed inadvertently
- Guidance system protected against spatters
Welding
- Individual adjustment options for optimum welding results
- Welding on painted sheets possible (clean, smooth and flat surfaces and grounding required)
- Manual or fully automatic stud feed possible (welding element is automatically pushed through the feed tube in the chuck)
.
