HBS-PC-C Production Center CNC Controlled



Application



  • All variations of stud welding



Options



  • Different stud welding units
  • Automatic stud feeder VBZ-3
  • Work piece fixtures
  • Machine protection cover
  • Custom made handling systems
  • Pneumatic clamp


Technical Data



Working range X-/Y-axis 19.69” x 11.02″ (500 x 280 mm)
T-slot work plate 27.56” x 14.76″ (700 x 375 mm)
Welding range #4 to 5/16”, dia. #4 to 5/16” (M3 to M8, dia. 3 to 8 mm);

dia. 3/8” to 1/2” (dia. 10 to 12.7 mm) only possible with modification

Stud length KAH 412: 0.31″ to 1.57″ (8 to 40 mm) other dimensions on request;

KAH 1: 0.31″ to 1.18″ (8 to 30 mm) other dimensions on request

Welding capacity Up to 15 studs/min (depending on stud welding unit, stud type and positioning of stud)
Stud feeding Automatic stud feeding by VBZ-3
Positioning (accuracy) of welded studs ± 0.008″ (± 0.2 mm)
Working stroke of welding head Z-max. = 4.92” (125 mm), z-adjustable = 0.16” to 1.77” (4 to 45 mm) bottom end stop
Manual hight adjustment Z = 1.77″ (45 mm)
Option welding head KAH 412, alternative KAH 1
Max. number of stud welding heads 1
Connections Electrical: 115 V, 16 A, 60 Hz

Pneumatic: 6 bar min/10 bar max./inner hose dia. 1/4″ (dia. 6 mm)

Dimension L x W x H 47.24” x 39.37” x 78.74″ (1,200 x 1,000 x 2,000 mm) without cover,

55.12” x 39.37” x 86.61″ (1,400 x 1,000 x 2,200 mm) with cover

Weight Approx. 374.78 lbs (170 kg)
Order No. 92-60-5028D



Advantages



Features



  • Advanced technology
  • High quality product
  • Cost savings
  • Microprocessor controlled
  • Controller for welding process
  • Reliable
  • Modular concept based on CAN-Bus-Technology



Structure



  • CNC-controlled
  • Fully automatic welding program
  • Storage: change into 10 programs 25 positions each or 20 programs 17 positions each
  • Micro processor controlled distance moving and program storage
  • Anti wear protection on work plate
  • Integrated zero-point-stop
  • Display for error indications
  • Roller-bearing guide
  • Ball bearing spindles
  • Ring initiator

Click edit button to change this text.

Suitable stud welding units



  • CDM 1601 (AT)
  • CDM 2401 (AT)
  • CDM 3201 (AT)
  • ARC 500
  • ARC 800
  • IT 1001
  • SCD 3201
