HBS-PC-S

HBS-PC-S


HBS-PC-S Production Center Standard Manual



Application



  • All variations of stud welding
  • With manual or automatic stud feeding (30% faster)



Options



  • Different stud welding units
  • Automatic stud feeder VBZ-3
  • Work piece fixtures
  • Machine protection cover
  • Custom made handling systems
  • Pneumatic clamp



Technical Data



T-slot work plate 19.69” x 14.76″ (500 x 375 mm )
Welding range #4 to 5/16”, dia. #4 to 5/16” (M3 to M8, dia. 3 to 8 mm);
dia. 3/8” to 1/2” (dia. 10 to 12.7 mm) only possible with modification
Stud length KAH 412: 0.31″ to 1.57″ (8 to 40 mm) other dimensions on request;

KAH 1: 0.31″ to 1.18″ (8 to 30 mm) other dimensions on request

Stud feeding Manual or automatic stud feeding (optional)
Positioning (accuracy) of welded studs ± 0.008″ (± 0.2 mm)
Working stroke of welding head Z-max. = 4.92” (125 mm), z-adjustable = 0.16” to 1.77” (4 to 45 mm) bottom end stop
Stud welding head KAH 412, alternative KAH 1
Max. number of stud welding heads 1
Connections Electrical: 115 V, 16 A, 60 Hz
Pneumatic: 6 bar min/10 bar max./inner hose dia. 1/4″ (dia. 6 mm)
Dimension L x W x H 47.24” x 39.37” x 78.74″ (1,200 x 1,000 x 2,000 mm) without cover,
55.12” x 39.37” x 86.61″ (1,400 x 1,000 x 2,200 mm) with cover
Weight Approx. 330.69 lbs (150 kg)
Order No. 90-70-5028D



Advantages



Features



  • Advanced technology
  • High quality product
  • Cost savings
  • Microprocessor controlled
  • Controller for welding process
  • Reliable
  • Modular concept based on CAN-Bus-Technology



Structure



  • Solid work table
  • Positioning of workpieces
  • Easy handling
  • Short set up time
  • Anti wear protection on work plate



Suitable stud welding units



  • CD 1501
  • CD 2301
  • CD 3101
  • CDM 1601 (AT)
  • CDM 2401 (AT)
  • CDM 3201 (AT)
  • ARC 500
  • ARC 800
  • IT 1001
  • SCD 3201
