Pro-Weld ARC-1850 Stud Welder

Pro-Weld ARC-1850 Stud Welder

ARC-1850 Stud Welder

  • Designed and built in U.S.A.
  • Constant current output
  • Single or dual gun systems
  • Independent gun controls
  • Precise weld time and weld current adjustments
  • Digital display of actual weld time and weld current
  • Diagnostic L.E.D.’s
  • State-of-the-art gun control circuitry
  • Built in chuck saver
  • Auto-safety shutdown



Learn About Our Rental Fleet



The Pro-Weld International

ARC-1850 is a compact and portable stud welding power supply capable of welding studs thru 7/8″ diameter weld base. The power supply which operates on single phase power has the added feature og weld current regulation that improves stud welding consistency. Both the weld time and weld current are infinitely adjustable for preciseness and repeatability.

A specially designed electronic gun control circuit has been incorporated to increase overall reliability. If a fault condition occurs due to a shorted gun solenoid or a faulty control cable, the circuit will prevent gun retriggering and eliminate damage to printed circuit boards.

Printable Specsheet



Components

Description Part No.
System, Dual 100-210D 1850
System, Single 100-210S 1850
Ground Cable 25′ x 4/0 125-0104 1850
Combo Cable 50′ x 4/0 125-1002 1850
Power Supply, Single 200-0022 1850
Power Supply, Dual 200-0023 1850
Weld Gun 300-0600 1850



Specifications

Dimensions 26″ H x 24″ W x 33″ D
Output 1850 Amps @ 45 VDC
Weight 500 lbs
Duty Cycle 12 GA-5/8 Unlimited
3/4 10/Min, 7/8 4/Min
Input 230/460/575 VAC
3 Phase 60HZ
Fusing 200/100/90 Delay Type
Time Control Stepless Adjustable
.1-1.6 sec
Current Control Stepless Adjustable
100-1900 Amps
