Pro-Weld ARC-800 Stud Welder

Pro-Weld ARC-800 Stud Welder

ARC-800 Stud Welder

  • Designed and built in U.S.A.
  • Regulated ouput current
  • Precise weld time and weld current adjustments
  • Storage Compartment
  • Diagnostic L.E.D.’s
  • State-of-the-art gun control circuitry
  • Thermally Protected
  • Portable
  • Easy access to control circuitry



Learn About Our Rental Fleet



The Pro-Weld International

ARC-800 is a compact and portable stud welding power supply capable of welding
studs thru 1/2″ diameter weld base. The fully regulated power supply which operates on
single phase power produces a smooth, stable welding arc. Both the weld time and weld
current are infinitely adjustable for preciseness and repeatability.

For maximum flexability the weld time can be switched between two ranges.
The expanded short time range provides fine adjustment of weld time for special short
cycle applications such as welding to thin materials.

A specially designed electronic gun control circuit has been incorporated to
increase overall reliability. If a fault condition occurs due to a shorted
gun solenoid or a faulty control cable, the circuit will prevent gun retriggering
and eliminate damage to printed circuit boards.

Printable Specsheet



Components

Description Part No.
System Complete 100-0211 800
Ground Cable 1/0 x 25′ 125-0102 800
Combo Cable 1/0 x 50′ 125-1000 800
Power Supply 200-0026 800
Weld Gun 300-0500 800



Specifications

Dimensions 36-1/2″ H x 16″ W x 14″ D
Output 900 Amps
Weight 150 lbs
Duty Cycle 1/4 14/Min, 5/16 12/Min,
3/8 10/Min, 1/2 5/Min
Input 208/230/460 VAC
Single Phase 60HZ
Fusing 100/100/50 Amps
Timer Control Stepless Adjustable
.05-.6 sec
Current Control Stepless Adjustable
100-900 Amps
