Pro-Weld CD-212 Capacitor Discharge Stud Welder
CD-212 Capacitor Discharge Stud Welder
- Designed and built in U.S.A.
- Light Weight
- Safety Fault Shut Down
- Recessed Control Panel
- Circuit Breaker Protection
- Powder Coated
The CD-212 is a state-of-the-art solid state capacitor
discharge stud/pin welder. Its lightweight design increases portability but with the power to weld 1/4″ diameter flanged studs.
The extremely short weld time of capacitor discharge
process allows studs to be welded to material as thin
as .015 without burn-through.
The unit is capable of welding mild steel, stainless and
aluminum studs.
Printable Specsheet
Parts List
| Description | Part No. |
|---|---|
| System Complete | 100-0112 |
| Ground Cable | 125-0100 |
| Power Unit Only | 200-0015 |
| Gun Only | 300-0100 |
Specifications
| Dimensions | 8-1/2″ H x 9″ W x 11-3/4″ D |
|---|---|
| Stud Range | 14 GA – 1/4″ |
| Weight | 26 lbs |
| Capacitance Charge | 66,000 MFD |
| Range | 45-200 VDC |
| Mode | Contact Gap (optional) |
| Weld Rate | 12 Studs/Min. |
| Input Power | 110 VAC, 60 HZ 20 amps |
