Pro-Weld CD-312 Capacitor Discharge Stud Welder
CD-312 Capacitor Discharge Stud Welder
- Designed and built in U.S.A.
- Safety Fault Shut Down
- Recessed Control Panel
- L.E.D. Panel Meter
- Diagnostic L.E.D.’s
- Powder Coated
Learn About Our Rental Fleet The Pro-Weld International CD-312 is a state of the art solid state capacitor discharge stud / pin welder. Its rugged design and user friendly controls makes it simple to set up and use. The extremely short weld time of capacitor discharge process allows studs to be welded to material as thin as .015 without burn-through. The unit is capable of welding mild steel, stainless and aluminum studs as well as cuphead pins. Printable Specsheet
Parts List
| Description | Part No. |
|---|---|
| System Complete | 100-0108 |
| Ground Cable | 125-0100 |
| Power Unit Only | 200-0012 |
| Gun Only | 300-0100 |
Specifications
| Dimensions | 8-1/2″ H x 10″ W x 16-1/2″ D |
|---|---|
| Stud Range | #2 – 5/16″ |
| Weight | 47 lbs |
| Capacitance Charge | 88,000 MFD |
| Range | 45-185 VDC |
| Mode | Contact Gap (optional) |
| Weld Rate | 24 Studs/Min. |
| Input Power | 110 VAC, 20 amps |
