Pro-Weld CD-512 Capacitor Discharge Stud Welder

CD 312


CD-512 Capacitor Discharge Stud Welder

  • Designed and built in U.S.A.
  • Safety Fault Shut Down
  • Recessed Control Panel
  • L.E.D. Panel Meter
  • Diagnostic L.E.D.’s
  • Powder Coated


Learn About Our Rental Fleet

The Pro-Weld International CD-512 is a state of the art solid state capacitor discharge stud / pin welder. Its rugged design and user friendly controls makes it simple to set up and use.

The extremely short weld time of capacitor discharge process allows studs to be welded to material as thin as .015 without burn-through.

The unit is capable of welding mild steel, stainless and aluminum studs as well
as cuphead pins.

Printable Specsheet


Parts List

Description Part No.
System Complete 100-0110
Ground Cable 125-0101
Power Unit Only 200-0013
Gun Only 300-0200


Specifications

Dimensions 8-1/2″ H x 13-1/4″ W x 16-1/2″ D
Stud Range #2 – 3/8″
Weight 55 lbs
Capacitance Charge 88,000 MFD Low, 176,000 MFD High
Range 45-185 VDC
Mode Contact Gap (optional)
Weld Rate 24 Studs/Min.
Input Power 110 VAC, 20 amps
