Talon Capacitor Discharge Stud Welder

Midwest Fasteners Talon - Capacitor Discharge Stud Welder



Midwest Fasteners Talon



  • Quick-charge Transformer
  • Stepless voltage Control
  • Digital LED Voltage Meter
  • On-Board LED Diagnostics
  • Visible On/Off Switch
  • Diagnostic L.E.D.’s
  • Posi-Weld Cup Head Chuck
  • Lightweight Easy-Grip Gun
Learn about our Rental Fleet

A revolution in welding technology is underway with Talon. Even though it weighs less than 30 lbs., there’s nothing lightweight about it!
Pound for pound, Talon offers the best performance ever in a portable pin welder.Inside and out, Talon includes innovations that make it the most reliable, user friendly, heavy duty welding system available. In fact, superior consistency and weld quality are Talon trademarks. And that’s especially true when welding cup head pins.

Talon technology is so dependable that it comes with a full three-year warranty. Combine its long service life and affordable price with savings in time and materials, and you’ll enjoy profitability like never before.

Printable Spec Sheet

Specifications



Height 8-1/2″
Width 10″
Depth 13″
Weight 29 lbs.
Weld Rate Up to 20/Min.
Weldable Materials Mild Steel, Stainless Steel, Aluminum
Pin/Stud Range 14 GA, thru 1/4″ Dia. Weld Base
Weld Voltage 35-175 VDC
Capacitance 70,000 Mfd
Weld Mode Contact, Cuphead
Power Requirement 115 VAC, 60 Hz, 20 Amp220V Export Model available



Weld Gun



Weight 1.6 lbs. (not including cable)
Size 4-7/8″ x 2″ x 5-3/4″
Weldable Dia. 14 Ga. thru 1/4″ Dia. Weld Base
Material High strength, impact resistant polycarbonate



Cables



Ground Cable #4 x 15 ft. (One Each)
Gun Extension Set #4 x 18/2 x 35 ft. (Direct to Gun)



Features



  • Quick-charge Transformer – Enjoy lighting fast duty cycles and excellent load-to-duty cycle characteristics. Talon’s newer, compact-design transformer offers outstanding balance between low weight and high performance.
  • Stepless voltage Control – Infinite weld-heat settings are now attainable with TALON’s “true” variable voltage control. At your fingertips is the full range of capacitance for all applications and the industry’s first “turn-down” feature.
  • Digital LED Voltage Meter – What you set is what you get! Operator’s love TALON’s large, color display of voltage settings. The high-definition LED read-out is easy to see on all types of jobs.
  • On-Board LED Diagnostics – Now you can troubleshoot welder problems anywhere they occur. Immediately! Front panel, color-coded LEDs help you to evaluate system status in an instant or pre-test your system before use in the field.
  • Visible On/Off Switch – TALON’s large, lighted On/Off toggle switch is easy to see. A separate, built-in circuit breaker eliminates fuses, protects your EAGLE and is easy to access.
  • Posi-Weld Cup Head Chuck – Eliminates the guesswork from cup head welding! This heavy-duty, one piece magnetic chuck delivers better, more consistent welding from any angle. From the first use, enjoy less scrap and fewer failures.
  • Lightweight Easy-Grip Gun – Crafted from high impact, nonconductive polycarbonate, its hand-friendly design continues our standard to easily adapt to all applications. parts and accessories are interchangeable and accessible for quick changeover.
