Annular Ring Navy

Annular Ring Navy Arc Weld Stud



Arc Weld Stud Tensile / Torque Strength Chart


Nom D Min L Rd Rl Ferrule Id
3/16 3/4″ .175 .312 F0187


Low Carbon Steel
C 0.23% max.
Mn 0.90% max.
P 0.04% max.
S 0.05% max.
Tensile 60,000 psi (min.)
Yield 50,000 psi (min.)
Elong 20% (in 2 inches)
Plating Plating is not standard. Cadmium, Copper, Nickel, and Zinc available upon customer request.


Stainless Steel
Mat Note AISI grade – 302/304/305 std. Other grades available upon request.
Plating Does not apply to Stainless
Mech Note Values for various grades available upon request.
