Deformed Concrete Anchor



Deformed Concrete Anchor Arc Stud Weld





D Min L Ferrule Id
1/4 3/4 F0250
3/8 3/4 F0375
1/2 1″ F0500
5/8 1″ F0625
3/4 1″ F0750



Low Carbon Steel
C 0.23% max.
Mn 0.90% max.
P 0.04% max.
S 0.05% max.
Tensile 60,000 psi (min.)
Yield 50,000 psi (min.)
