Headed Concrete Anchor
Headed concrete anchors are available for welding to flat surfaces, inside angles, and outside angles. Each of these applications requires the proper style stud and ferrule, so please specify your application when ordering studs.
| D | Min L | Hd | Ht | Ferrule Id |
|---|---|---|---|---|
| 1/4 | 3/4 | 1/2 | 3/16 | F0250 |
| 3/8 | 3/4 | 3/4 | 9/32 | F0375 |
| 1/2 | 1″ | 1″ | 5/16 | F0500 |
| 5/8 | 1″ | 1-1/4 | 5/16 | F0625 |
| Low Carbon Steel | |
|---|---|
| Mat Note | AISI C1010 through C1020 |
| Tensile | 55,000 psi (min.) |
| Elong | 20% (in 2 inches) |
