| D | Min L | Min Id | Min E | Ferrule Id |
|---|---|---|---|---|
| 3/16 | 1-1/8 | 1/2 | 1 | F0187 |
| 1/4 | 1-1/4 | 5/8 | 1-1/8 | F0250 |
| 5/16 | 1-1/2 | 3/4 | 1-1/4 | F0312 |
| 3/8 | 1-5/8 | 7/8 | 1-3/8 | F0375 |
| 7/16 | 1-3/4 | 1 | 1-1/2 | F0437 |
| 1/2 | 2 | 1 | 1-1/2 | F0500 |
| 5/8 | 2-1/2 | 1-1/2 | 1-7/8 | F0625 |
| Low Carbon Steel | |
|---|---|
| C | 0.23% max. |
| Mn | 0.90% max. |
| P | 0.04% max. |
| S | 0.05% max. |
| Tensile | 60,000 psi (min.) |
| Yield | 50,000 psi (min.) |
| Elong | 20% (in 2 inches) |
| Plating | Plating is not standard. Cadmium, Copper, Nickel, and Zinc available upon customer request. |
| Stainless Steel | |
|---|---|
| Mat Note | AISI grade – 302/304/305 std. Other grades available upon request. |
| Plating | Does not apply to Stainless |
| Mech Note | Values for various grades available upon request. |
