Long Reduced Base



Long Reduced Base Arc Weld Studs



Arc Weld Stud Tensile / Torque Strength Chart



D Min L Bd Min Bl Fd Fh Ferrule Id
1/4 3/4 .187 .375 .281 .109 FS187
5/16 3/4 .250 .375 .359 .125 FS250
3/8 3/4 .312 .375 .437 .125 FS312
7/16 1 .375 .375 .500 .140 FS375
1/2 1 .437 .437 .578 .140 FS437
5/8 1-1/4 .500 .500 .656 .156 FS500
3/4 1-1/2 .625 .718 FS625



Low Carbon Steel
C 0.23% max.
Mn 0.90% max.
P 0.04% max.
S 0.05% max.
Tensile 60,000 psi (min.)
Yield 50,000 psi (min.)
Elong 20% (in 2 inches)
Plating Plating is not standard. Cadmium, Copper, Nickel, and Zinc available upon customer request.



Stainless Steel
Mat Note AISI grade – 302/304/305 std. Other grades available upon request.
Plating Does not apply to Stainless.
Mech Note Values for various grades available upon request.
