No Thread

No Thread Arc Weld Studs



Arc Weld Stud Tensile / Torque Strength Chart



D Min L Fd Fh Ferrule Id
3/16 3/4 .281 .093 F0187
1/4 3/4 .359 .109 F0250
5/16 3/4 .437 .109 F0312
3/8 3/4 .500 .125 F0375
7/16 3/4 .578 .140 F0437
1/2 7/8 .627 .156 F0500
5/8 1 .796 .187 F0625
3/4 1-1/8 .937 .250 F0750
7/8 1-1/4 1.093 .312 F0875
1 1-1/2 1.312 .375 F1000



Low Carbon Steel
C 0.23% max.
Mn 0.90% max.
P 0.04% max.
S 0.05% max.
Tensile 60,000 psi (min.)
Yield 50,000 psi (min.)
Elong 20% (in 2 inches)
Plating Plating is not standard. Cadmium, Copper, Nickel, and Zinc available upon customer request.



Stainless Steel
Mat Note AISI grade – 302/304/305 std. Other grades available upon request.
Plating Does not apply to Stainless.
Mech Note Values for various grades avaiable upon request.
