Rectangular Plain



Plain Rectangular Arc Weld Studs



Arc Weld Stud Tensile / Torque Strength Chart



W Min L Fw Fl Fh Ferrule Id
3/8 7/8 .218 .437 .125 R0375
5/8 1″ .218 .687 .156 R0625



Low Carbon Steel
C 0.23% max.
Mn 0.90% max.
P 0.04% max.
S 0.05% max.
Tensile 60,000 psi (min.)
Yield 50,000 psi (min.)
Elong 20% (in 2 inches)
Plating Plating is not standard. Cadmium, Copper, Nickel, and Zinc available upon customer request.
