Rectangular T Slotted



Rectangular T Slotted Arc Weld Studs



Arc Weld Stud Tensile / Torque Strength Chart



W Min L Oh Sh X Sw B Fw Fl Fh Ferrule Id
3/8 1/2 .322 .531 .765 .130 .122 .218 .437 .125 R0375
5/8 1/2 .500 1.000 1.250 .255 .185 .218 .687 .156 R0625



Low Carbon Steel
C 0.23% max.
Mn 0.90% max.
P 0.04% max.
S 0.05% max.
Tensile 60,000 psi (min.)
Yield 50,000 psi (min.)
Elong 20% (in 2 inches)
Plating Plating is not standard. Cadmium, Copper, Nickel, and Zinc available upon customer request.



Stainless Steel
Mat Note AISI grade – 302/304/305 std. Other grades available upon request.
Plating Does not apply to Stainless
Mech Note Values for various grades available upon request.
