Shear Connector
Shear Connectors are available for welding to flat surfaces, inside angles, outside angles, and “thru deck”.
Each of these applications requires the proper style stud and ferrule, so please specify your application when ordering studs.
| D | Min L | Hd | Ht | Ferrule Id |
|---|---|---|---|---|
| 3/4 | 1-1/2 | 1-1/4 | 3/8 | F0750 |
| 7/8 | 1-3/8 | 1/-3/8 | 3/8 | F0875 |
| Low Carbon Steel | |
|---|---|
| Mat Note | AISI C1015, C1018, or C1020 |
| Tensile | 60,000 psi (min.) |
| Yield | 50,000 psi (min.) |
| Elong | 20% (min.) |
| Reduction Of Area | 50% (min.) |
