Shoulder Threaded

Shoulder Threaded Arc Weld Studs
Arc Weld Stud Tensile / Torque Strength Chart



D Min L Td Max Tl Fd Fh Ferrule Id
1/4 .312 #8 .437 .359 .109 F0250
5/16 .375 #10 .500 .437 .109 F0312
3/8 .375 1/4 .750 .500 .125 F0375
7/16 .437 5/16 .875 .578 .140 F0437
1/2 .500 3/8 1.000 .627 .156 F0500
5/8 .625 1/2 1.250 .796 .187 F0625
3/4 .625 5/8 1.625 .937 .250 F0750
7/8 .750 3/4 1.875 1.093 .312 F0875



Low Carbon Steel
C 0.23% max.
Mn 0.90% max.
P 0.04% max.
S 0.05% max.
Tensile 60,000 psi (min.)
Yield 50,000 psi (min.)
Elong 20% (in 2 inches)
Plating Plating is not standard. Cadmium, Copper, Nickel, and Zinc available upon customer request.



Stainless Steel
Mat Note AISI grade – 302/304/305 std. Other grades available upon request.
Plating Does not apply to Stainless
Mech Note Values for various grades available upon request.
