| BD | T | TD | BL | L |
|---|---|---|---|---|
| 1/2 | 1/4-20 | 0.750 | 1.000 | 1.625 |
| 5/8 | 3/8-16 | 0.750 | 1.000 | 1.750 |
| 3/4 | 1/2-13 | 0.750 | 1.000 | 1.750 |
| Note | To Order |
|---|---|
| Special Sizing Available Upon Request. | Specify Base Diameter and Material. |
.
Stack Studs (Stud Extenders)
| BD | T | TD | BL | L |
|---|---|---|---|---|
| 1/2 | 1/4-20 | 0.750 | 1.000 | 1.625 |
| 5/8 | 3/8-16 | 0.750 | 1.000 | 1.750 |
| 3/4 | 1/2-13 | 0.750 | 1.000 | 1.750 |
| Note | To Order |
|---|---|
| Special Sizing Available Upon Request. | Specify Base Diameter and Material. |
.
