Standard (Partial) Thread

Standard Thread - Arc Weld StudsStandard Thread - Arc Weld Studs Photo



Arc Weld Stud Tensile / Torque Strength Chart



D Min L Bd Min Bl Fd Fh Ferrule Id
1/4 3/4 .215 .375 .312 .093 P0250
5/16 3/4 .275 .375 .406 .109 P0312
3/8 3/4 .330 .390 .468 .109 P0375
7/16 3/4 .387 .437 .531 .125 P0437
1/2 7/8 .446 .500 .593 .156 P0500
5/8 1 .562 .625 .750 .187 P0625
3/4 1-1/4 .680 .796 .920 .250 P0750
7/8 1-3/8 .798 .859 1.046 .312 P0875
1 1-1/2 .913 .921 1.187 .375 P1000



Low Carbon Steel
C 0.23% max.
Mn 0.90% max.
P 0.04% max.
S 0.05% max.
Tensile 60,000 psi (min.)
Yield 50,000 psi (min.)
Elong 20% (in 2 inches)
Plating Plating is not standard. Cadmium, Copper, Nickel, and Zinc available upon customer request.



Stainless Steel
Mat Note AISI grade — SS-316. Other grades available upon request.
Plating Does not apply to Stainless Steel.
Mech Note Values for various available upon request.
