Flanged Annular Ring Navy



Flanged Annular Ring Navy



Capacitor Discharge Weld Stud Tensile / Torque Strength Chart



Nom D Min L Rd Rl
1/8 3/4 .122 .312
3/16 3/4 .175 .312



Low Carbon Steel
Mat Note Conforms to MIL-S-24149
Tensile 60,000 psi (min.)
Yield 50,000 psi (min.)
Elong 20& (in 2 inches)
Plating Copper coating is standard



Stainless Steel
Mat Note Conforms to MIL-S-24149
Plating Does not apply to Aluminum
Mech Note Values for various grades available upon request
