Pro-Weld ARC-656M (Modified) Stud Welder

pro-weld arc-656m

ARC-656M (Modified) Stud Welder

  • Designed and built in the U.S.A.
  • Precise weld time adjustments
  • Lightweight aluminum cabinet
  • Short cycle capabilities
  • Diagnostic L.E.D.’s
  • State-of-the-art gun control circuitry
  • Portable
  • 1 Year warranty on Printed Circuit Board
  • Powder Coated

ARC 656, A Cost-Saving Welding System

The Pro-Weld InternationalARC-656 is a compact, lightweight stud welding power supply capable of welding
studs thru 1/2″ diameter reduced weld base. The power supply, which operates on
three-phase power, produces a smooth, stable welding arc. The front panel digital
display indicates the weld time, which is infinitely adjustable for preciseness
and repeatability.

The expanded time range provides fine adjustment of weld time for special short
cycle applications such as welding to thin materials.

A specially designed electronic gun control circuit has been incorporated to
increase overall reliability. If a fault condition occurs due to a shorted
gun solenoid or a faulty control cable, the circuit will prevent gun retriggering
and eliminate damage to printed circuit boards.

Printable Specsheet

Components

Description Part No.
System 100-0215 656
w/ Dampner 100-0216 656
Ground Cable 15ft x #2 125-0101 656
Power Supply 200-0027 656
Weld Gun w/ 50′ Cable Length 300-0802 656
w/ Dampner 300-0803 656

Specifications

Dimensions 8-1/4″ H x 11-1/4″ W x 17″ D
Output 650 Amps @ 36 VDC
Weight 77 lbs
Duty Cycle 3/8″ 8/Min
Input 230/460/575 VAC
3 Phase 60 Hz
Fusing 60/30/30
Delay Type
Time Control .015-1.00 sec

.
